Performance | |
Steam output | 168 kg/h. |
Heat output | 111.600 kcal |
Operating pressure | 1-10 bar |
Max. operating pressure | 11.5 bar |
Max. steam temperature | 184,0 °C |
Number of heating elements | 2x 7x 9kW |
Electrical dimensions | |
Operating voltage | 400 Volt |
50 Hz | |
3+PE phases | |
Heating power | 2x 63 kW |
Total connected load | 2x 64 kW |
Rated current | 2x 92 A |
Protection on site | 2x 100 A |
Min. cross section | 2x 4x35 mm² |
Connector plug | 2x CEE 125A |
Installation dimensions | |
Steam pipe | DN25 |
Water intake | ET R½" |
Blowdown valve | DN20 |
Safety valve | DN25 |
Emissions | |
Noise | 63 db |
Dimensions | |
Height | 2.136 mm |
Width | 1.200 mm |
Depth | 1.200 mm |
